Processing CellCleanCELL 3220
CleanCELL 3220 has a substantial cleaning space, making it ideal for your large-area components. Its customizable automation works well for pre- and post-welding treatment, paint stripping from metallic surfaces, delamination, surface modification, and cleaning tools.
With all of the benefits and features of the CleanCELL 2220, the 3220 also allows for a larger working envelope and more automation options. The machine can be loaded manually or automatically, has a user-friendly touch screen, and it comes in low-, mid-, or high-power options.
- Automating repeatable cleaning processes
- Precision coating removal
- Pre-treatment for welding and bonding
- Post-welding treatment
CleanCELL 3220 Features
- 01Large workspace
- 02Unrestricted 3-shift operation
- 03Compact, steel frame
- 04Touchscreen operation
- 05Customization options including axis expansion, water cooling, height adjustments, additional integrations, and more
- 06Support for more than 10 languages
- 07Automatic path generation available through CAD-CAM processor
- 08cleanSTUDIO graphical control software
- 09High-performance Siemens servo drives
Dimensions
- Working envelope (in)
- 60 × 28 × 11
- External dimensions (in)
- 81W × 87L × 87H
- Weight
- 3,197 lbs
- Laser equipment
- Low, Mid, or High Power
- Number of axes
- 6
- Axis types
- Spindel or optional linear motor, H-portal
Dimensions reflect the base model. Modifications can alter the dimensions of the actual unit.
cleanCELL 3220 Paint Removal batterybox contourSCAN
Built for Your
Unique Needs
If your organization has a particular demand that's unique within your industry, Adapt Laser can design an exclusive, customized cleaning application that fits your needs — working with multiple robotic options and automation integrators to build-to-order your laser solution.
